Bottle Washing Machine

Model: XFY-TXP


Multi-functional bottle washing machine is used for washing glass bottle with special-shape or round bottle. Automatic bottle washing machinery adopts the new technology of parallel bottle folder to convey the bottle, in addition, the distance of chain belt can be adjustable, so the machine has the advantage of adaptability and reliability.


1. This multi-functional bottle washing machine is equipped with water vapor dealing system, which has the advantages of smooth operation, easy maintenance and cleansing effect.
2. Each bottle can be washed by multi-channel recycle water, pure water and purification compression air, up to ideal cleaning effect.


Model XFY-TXP Multi-Functional Bottle Washing Machine
Capacity 60 to 120 B/M
Range of bottles 50 to 600ml
Flowing of recycle water 0.5 to 1 m3/h Pressure 0.2 to 0.3MPa
Consumption of purification water 0.5 to 0.6 m3/h
Consumption of compressed air 0.6 m3/min
Power supply of automatic bottle washing machinery 380V, 50Hz, three-phase four-wire system
Power 2 kW
Dimension 2400×1500×1500 mm
